Jackery Explorer E500 V2 + 100WAIR SolarSaga Solar Panel
SKU: 60-050010-US00264
|
The smallest volume in the same capacity segment
|
|
Large capacity and Big power: Meet the power supply needs of outdoor camping equipment and emergency power supply needs of home office (home printer/copier, desktop computer)
|
|
One-touch energy-saving mode reduces battery consumption and ensures long-lasting battery life
|
|
100W solar recharging + 100W USB-C output, can carry Starlink 20H (for outdoor Starlink mini)
|
|
10ms UPS, seamless power switch to power CPAP & computer & network equipment
|
|
3kv, ≥1000 joule surge protection function, to ensure safe power supply for sensitive household devices during lightning weather
|
JACKERY EXPLORER E500 V2 SPECIFICATIONS
|
Product
|
Jackery Explorer E500 V2
|
|
Capacity
|
512Wh
|
|
Watt
|
Rated 500W，Peak rated 1000W
|
|
2x AC Output
|
2个，Total 500W max
|
|
1x USB-A Output
|
18W Max
|
|
2x USB-C Output
|
USB-C*1:100W Max
USB-C*2：30W Max
|
|
Charge Time
|
1. AC Charge： 80 mins
2. AC+DC charge： 60 mins
3. DC Charge： 200 mins
|
|
AC Input
|
AC charging power up to 550W @25℃
|
|
DC Input
|
Via 1*8020 ，200W Max
Solar ：16~60V---10.5A
Car：11~16V--- 8A Max
|
|
Car port
|
12V, 10A Max
|
|
Battery / Cycling
|
LFP / 6000 Cycles ≥70%
|
|
UPS/防浪涌
|
≤10ms / Surge Protection（3kv、≥1000 joule）
|
|
LED
|
Two Modes: Bright & SOS
|
|
Dimensions
|
31*20.5*15.6cm
|
|
Product Weight
|
5.7kg
|
|
Discharge temperature
|
-20°C~45°C
|
|
Charge temperature
|
-20°C~45°C
|
|
Storage temperature
|
1 year: 0~25℃, 3 months: 0~45℃, 1 month: -20~45℃
|
|
Warranty
|
3+2 years
|
Jackery 100WAIR SolarSaga Solar Panel
Weight: 7.9 lbs (3.6 kg)
Warranty: 3+2 Years
Waterproof: IP68
Efficiency rate: 25%
Charging Lead length: 3 Meters
Operating temperature: -4℉~149℉ (-20°C~65°C)
Protection Class Against Electric Shock: Class II
Ports USB-A Output: 5V⎓2.4A
USB-C Output: 5V⎓3A
Solar Peak Power STC: 100W±5W, BNPI: 104W±5W
Power Voltage STC: 20.0V±5%, BNPI: 20.1V±5%
Power Current STC: 5.0A±5%, BNPI: 5.2A±5%
Open Circuit Voltage STC: 24.8V±5%, BNPI: 25V±5%
Short Circuit Current STC: 5.4A±5%, BNPI: 5.8A±5%
Maximum System Voltage: 60V
Maximum Reverse Current: 15A
Bifaciality Coefficient (back/front): Pmax>30%, Voc>95%, Isc>32%
What's in the Box:
1 x Explorer 500 v2
1 x AC Charge Cable
1 x SolarSaga 100W Solar Panel
1 x 3m Solar Panel Connection Lead
1 x User Manual
