MAKINEX
Couldn't load pickup availability
The Makinex portable power box is a quiet, clean, and safe power solution. It provides noise-free, fuel-free, emissions-free power, ideal for indoors and confined spaces. This versatile device offers continuous power up to 6kW with 15 kWh battery capacity. It charges via 240V mains or solar PV and includes 3x15A outlets, 2x5V USB-A outlets, RCD protection, and a battery management display. With thermal overload protection, a spring-actuated brake, and a durable frame, it’s easy to maneuver and store. The IP44-rated generator ensures weather resistance, reliability, and durability. Charge overnight and enjoy 6kW output whenever you need quiet & emission-free power.
|
PPB-8 |
||
|
Code |
PPB8-10 -> 9.6 kWh variant |
|
|
PPB8-15 -> 14.4 kWh variant |
||
|
Outlet socket |
15A - 230V |
|
|
USB Charger 5V 2.1A |
||
|
Inlet |
10A – 230V (Trickle Charge) |
|
|
4kW Solar Panel |
||
|
Inverter |
1 x 48V / 8kW |
|
|
Charging Time |
7.5 hours (15 kWh) |
|
|
|
||
|
Inverter |
||
|
Rated Inverter Power (Continuous) |
8kW |
|
|
Surge Capacity (Peak) |
16kW for 5 Secs |
|
|
Nominal Output Voltage |
230VAC |
|
|
Frequency |
50Hz |
|
|
AC Voltage Regulation (Battery Mode) |
230VAC ± 5% |
|
|
Battery Nominal Voltage |
48VDC |
|
|
Overload Protection |
100ms @ ≥205% load 5s @ ≥150% load 10s @ 110%~150% load |
|
|
AC Input |
Nominal 230VAC Range 170-280VDC |
|
|
Nominal Input Frequency |
50Hz |
|
|
Max Feed Through Current |
10A |
|
|
|
||
|
Lithium Batteries |
||
|
Battery Nominal Voltage |
48VDC |
|
|
Battery Voltage Window |
40.5-54VDC |
|
|
Battery Nominal Capacity |
4800Wh |
|
|
Battery Type |
LiFePO4 (LFP) |
|
|
Batter Manufacturer |
FNSPower |
|
|
Battery Number |
3 |
|
|
Battery Management System |
Yes |
|
|
Operating Temperature |
Charge |
0℃ ~ 45℃ |
|
Discharge |
-20℃ ~ 50℃ |
|
|
|
||
|
Solar Panel Inlet |
||
|
PV Rated Power |
4kW |
|
|
Max. PV Open Circuit Voltage |
500VDC |
|
|
PV Array MPPT Voltage Range |
90-450VDC |
|
|
Max PV Input Current |
18A |
|
|
Startup Voltage |
80VDC ± 5VDC |
|
|
Dimensions & Weight |
|
|
Dimensions |
972 x 516 x 931 mm LENGTH x WIDTH x HEIGHT |
|
Dry Weight |
PPB8-10 -> 163 kg |
|
PPB8-15 -> 205 kg |
|
|
ON BOARD CONTROL PANEL EQUIPPED WITH: |
|
|
Battery Monitor |
Run and Charging Time SOC monitoring Voltage/Current/Power monitoring |
|
Battery ON/OFF switch |
Fitted |
|
Battery Isolator |
Fitted |
|
USB Charger |
Fitted |
|
RCBO Protection |
Fitted |
|
Distribution Panel |
|
3x 15A 1Ph 230V 3 Pin GPOs (RCBO Protected) |
|
1x 10A 1Ph 230V 3 Pin Inlet Trickle Charge (RCBO Protected) |
|
1x Solar Input Touch Safe Connector (Makinex PV Adaptor Cable required) |
|
2 x USB Charger 5V 2.1A |
|
Standard Features |
|
Removable top cover for access to batteries, inverter, and electrical wiring (maintenance should not, however, be required) |
|
Renogy Battery Management Display |
|
Self-actuating brake – holds the unit on inclines up to 8 deg |
|
Durable HDPE bumpers to avoid damage to the main sheet-metal structure |
|
Lifting eye allowing for easy access from trailers |
|
Tie-down strap locations on the top and the bottom (both the front and back of unit) |
