Aurora Generators 8kW 48 Volt DC Generator/ No Canopy Enclosure - PowerGen USA

DC Generators are a fast and convenient way to charge batteries. AURORA DC Generators like this one use liquid engines, slow-turning diesel engines for less noise, more power and super long life.

 Auto-Start is included and is compatible with all two-wire starting systems.

 Optional large fuel tank and remote monitoring and control are also available.

ENGINE SPECIFICATIONS

 • Manufacturer | Yanmar

• Model - 3TNV70-GGE |  TIER4 Final Emission Standard

• Three Cylinder

• Power Output - 6 kWe

• Emission Certification - Tier 4 Final
• RPM - 1800

• Displacement -

• Glow Plugs

 ALTERNATOR SPECIFICATIONS

• MeccAlte | Zanardi  or Linz Electric

• Model - AL3-A 1S or 4V48 ESB4-48

• 48 Volts  (45-58 Volts Adjustable)

• Current | 125 Amp

• Efficiency 82%

• Ripple < 3%

• RPM | 1800

• Regulation | Electronic RT-DC Regulator

• Voltage accuracy -+ 2%

• Cooling | Winding Fan / Rectifier: Electric Fan

• Protection | Underspeed & Exciter Current

• Insulation | Chass H

• Temperature Rise | Class H

• Protection | IP 21

 INSTRUMENTATION & CONTROL

• Advanced Generator Controller

• Make - DynaGen

• Model - TG350

• Auto-Start & two-wire remote start compatible.

• Displays voltage, speed, frequency, battery, fuel level, oil pressure, coolant temp, and more.

• 150 Event Log

• Easy to use.

• User re-programmable

• Password Protected

 FUEL TANK

• Integral 45L / 12 Gallon Welded Steel Tank

• Electronic Fuel Level Sensor

• Vented Fuel Fill / Cap

 CONSTRUCTION

• All stainless steel fasteners used.

• Powder-coated steel enclosure

• Powder-coated steel frame

• Vibration Mounts on engine and alternator

• Dimensions -  57" x 33" x 40" (L x W x H)

• Weight - 950 lbs

 WHAT'S INCLUDED

• Includes Battery & Cables

• Includes Temperature Sensor

• Includes Radiator Coolant Level Sensor

WARRANTY

2 Years/2000 Hours
