Jackery
Jackery SolarSaga 200W Solar Panel - PowerGen USA
Jackery SolarSaga 200W Solar Panel - PowerGen USA
Regular price
$479.00 USD
Regular price
$699.00 USD
Sale price
$479.00 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
SKU: 21-0002-000063
- IP68 Waterproof Rating
- Bifacial Solar Panel, Improved Charging Efficiency
- Convenient Carrying
- Built to Last
Features Summary
Excellent Conversion Efficiency
With a power rating of 200W, it provides the fastest solar charging experience in Jackery's current solar panel lineup. It's equipped with adjustable stands and are made with monocrystalline solar cells and a honeycomb light trapping design.
Designed to Last
The ETFE-laminated design make it extremely temperature and corrosion resistant, with a functioning temperature range of -20-65℃(-4-149°F). The battery grid is designed on the back of the panel, preventing battery cracks whilst giving longer battery life.
SPECIFICATION
Ports
USB-A Output:5V⎓2.4A
USB-C Output:5V⎓3A
Electrical Data (STC)
Peak Power (Pmax):200W±5%
Open Circuit Voltage (VOC):24.8V±5%
Short Circuit Current (Isc):11.2A±5%
Power Voltage (Vmp):20V±5%
Power Current (Imp):10A±5%
Electrical Data (BNPI)
Peak Power (Pmax):208W±5%
Open Circuit Voltage (Voc):25V±5%
Short Circuit Current (Isc):11.4A±5%
Power Voltage (Vmp):20.2V±5%
Power Current (Imp):10.3A±5%
Dimensions
Folded:24.21 x 21.73 x 1.57 in (615 x 552 x 40 mm)
Unfolded:92.13 x 21.73 x 0.98 in (2340 x 552 x 25 mm)
Weight:13.67 lbs ± 0.66 lbs. (6.2 kg±0.3 kg)
General
Warranty:3+2 Years
Maximum System Voltage:60V
Maximum Reverse Current:15A
Protection Class Against Electric Shock:Class II
Waterproof:IP68
Operating temperature:-4℉~149℉（-20°C~65°C）
Voltage Temperature Coefficient:-0.268%/°C
Power Temperature Coefficient:-0.29%/°C
Bifaciality Coefficient :Pmax>30%, Voc>95%, Isc>32%
Portable Power Station
Explorer 3000 Pro:Up to 6 Pcs (with 2 solar connectors)
Explorer 2000 Pro:Up to 6 Pcs (with 2 solar connectors)
Explorer 1500 Pro:Up to 4 pcs (with 2 solar connectors)
Explorer 1500:Up to 2 Pcs
Explorer 1000 Pro:Up to 4 Pcs (with 2 solar connectors)
Explorer 1000:Up to 1 Pc
